The TAURUS ARC 200 DP single phase, 200A, 220V stick-electrode welding machine is designed and manufactured to the latest digital-inverter technology for demanding industrial applications. The pulsed MMA welding system offers even stirring of the molten pool, eliminating porosity and ensures firm and deep penetration welding. It is a compact light-weight inverter machine which ensures a clean, high-quality weld and excels in basic and rutile electrode welding. The advanced power input system will detect and handle a voltage drop or a spike of up to 25%. This will not only safeguard the machine against damage resulting from erratic power supply, but will also ensure smooth, uninterrupted operation. Professional and DIY welders can experience the built-in characteristics of anti-stick, hot-start and arc-force.
| SPECIFICATION | DESCRIPTION |
| PRODUCT CODE | TA-ARC200DP |
| MODEL | ARC-200DP |
| RATED POWER SUPPLY INPUT | 220V±25% SINGLE PHASE |
| DUTY CYCLE 40°C @ 10 MINUTES | 60% @ 200A |
| OPEN CIRCUIT VOLTAGE | 62V |
| WELDING CURRENT RANGE | 20 – 200A |
| ELECTRODE SIZE | 2.0 – 5.0mm |
| DIMENSIONS(mm) AND NET WEIGHT(kg) | 465 x 225 x 320mm ▪ 5.5kg |
