TAURUS MIG/MMA-205T COMPACT WELDER – 220V

SKU TA-MIG205T Categories ,
  • Uncomplicated design and appearance. The multi layer control circuit board and solid machine structure facilitate easy maintenance.
  • High efficiency and duty cycle and a noiseless rectifier.
  • A 25% Voltage fluctuation safeguard.
  • A stable welding process and excellent arc self regulation is ensured by the closed loop control system regulating a stable voltage in cases of grid voltage fluctuation.
  • Less spatter and a high metal deposition rate. as well as excellent weld seam appearance and low metal distortion.
  • Troubleshooting is minimised by the protection circuit ensuring safety and reliability.
  • The MMA function allows the use of a variety of different diameter electrodes such as acid, alkaline, stainless steel, and cast iron.



This Taurus MIG-205T welding machine is a high performance semi-automatic welding machine for CO2 and mixed gas shielded welding. The advanced power input system will detect and handle a voltage drop or a spike of up to 25%. This will not only safeguard the machine against damage resulting from erratic power supply, but will also ensure smooth, uninterrupted operation. It can weld low carbon steel, low alloy steel, stainless steel and other components. It uses Φ0.8-Φ1.0mm diameter stainless steel welding wire, steel wire, flux-cored wire and other solid wire. It is portable can be applied to fabrication and other industries. This MIG inverter welding machines have reasonable static characteristics and good dynamic performance and they are manufactured in accordance with IEC60974-1, Safety Requirements for Arc Welding Equipment.



ACCESSORIES

  • Earth clamp cable kit.
  • MIG torch.
  • Argon flowmeter



SPECIFICATION

DESCRIPTION

PRODUCT CODE TA-MIG205T
MODEL MIG205T
POWER SUPPLY VOLTAGE 220V±25% SINGLE PHASE
DUTY CYCLE 40°C @ 10 MINUTES 35% @ 200A(MIG) ▪ 35% @ 180A(MMA)
OPEN CIRCUIT VOLTAGE 56V
WELDING RANGE 50 TO 200A
WIRE DIAMETER 0.8 TO 1.0mm
PACKAGE DIMENSIONS(MM) AND NET WEIGHT(KG) 640 x 370 x 450mm   ▪  18.5KG
